1.0mpa Air Source Treatment Unit Pneumatic Booster Regulator Valve Air Tank Accessories

Product Categories

FENGHUA FLUID AUTOMATIC CONTROL CO.,LTD

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Ask Lasest Price
Brand Name :	FLUIDAC or OEM
Model Number :	VBA10A
Payment Terms :	TT Advance/30% deposit,70% by copy Bill oflading,Western Union,Paypal
Supply Ability :	1000PCS per Month
Delivery Time :	Within 20 days after receiving payment or deposit

Add to Cart

Pneumatic Booster Regulator Valve Air Tank Accessories Air Pressure Regulator VBA Combination

Features:

How to order:

Specifications:

Standard Specification
Model	VBA10A-02	VBA20A-03	VBA40A-04	VBA22A-03	VBA42A-04	VBA43A-04	VBA11A-02
Fluid	Compressed Air
Pressure increase ratio	Twice						2 to 4 times
Pressure adjustment mechanism	Knob-operated with refief mechanism			Air-operated		Knob-operated with relief mechanism
Max.flow rate(L/min(ANR))	230	1000	1900	1000	1900	1600	70
Set pressure range(Mpa)	0.2 to 2.0	0.2 to 1.0		0.2 to 1.0		0.2 to 1.6	0.4 to 2.0
Supply pressure range(Mpa)	0.1 to 1.0
Proof pressure (Mpa)	3	1.5				2.4	3
Port size(Rc)(IN/OUT/EXH:3 location)	1/4"	3/8"	1/2"	3/8"	1/2"		1/4"
Pressure gauge port size(Rc)(IN/OUT:2 locations)	1/8"
Tank connection port(with plug)	1/4"	3/8"	1/2"	3/8"	1/2"		1/4"
Ambient and fluid temperature(℃)	2 to 50 ( not freezing)
Installation	Horizontal
Lubrication	Grease( Non-lube)
Weight(kg)	0.84	3.9	8.6	3.9	8.6	8.6	0.89
